AudioCodes RXV200 Compute Device for small to mid size meeting rooms. The Bundle also Includes the RXPanel, RX15 Speakerphone and RXVCam50M

Avaibility-

In stock

SKU-RXV200-B360

£1,588.82

RXV200-B360 Bundle for Small/Medium Rooms: RXVCam360 + RX-PAD + RXV200

Free Next Day Delivery over £1233.99.

Price Match Guarantee.

Talk to a Expert on Live Chat.

SKU: RXV200-B360

The RXV200-B360 bundle includes the center-of-room RXVCam360 panoramic video camera with built-in speakers and microphones and is ideal for small/medium rooms with participants seated around a round table.

SKU

RXV200-B360

Specification

Performance
Product type	Group video conferencing system
Number of persons	18 person(s)
Product colour	Black
Bluetooth	Yes
Bluetooth version	5.0
Number of cameras	1
Technical details
Product type	Group video conferencing system
Number of persons	18 person(s)
Product colour	Black
Bluetooth	Yes
Bluetooth version	5.0
Number of cameras	1
Video
HD type	4K Ultra HD
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 2560x1440@30fps, 3840x2160@30fps
Megapixel (approx.)	5 MP
Video formats supported	MJPG, NV12, YUV
Aspect ratio	16:9
Supported graphics resolutions	640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
Maximum frame rate	30 fps
Maximum video resolution	3840 x 2160 pixels
Audio
Microphone pick-up range	3 m
Frequency range	100 - 20000 Hz
Output voltage Total Harmonic Distortion (THD)	5%
RMS rated power	8 W
Built-in speaker(s)	Yes
Automatic gain control	Yes
Number of speakers	1
File formats
Video formats supported	MJPG, NV12, YUV
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB connector type	USB Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Interface module
Interface module HDMI ports quantity	3
Interface module Ethernet LAN (RJ-45) ports	1
Interface module HDMI input ports quantity	1
Interface module HDMI output ports quantity	2
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Supported network protocols	TCP/IP (IPv4)
Security algorithms	256-bit AES
Networking standards	IEEE 802.1Q, IEEE 802.1p
Quality of Service (QoS) support	Yes
VLAN support	Yes
Camera
Image sensor size	1/2.7"
Focal length range	2.49 mm
Field of view (FOV) angle	360°
Effective sensor resolution	5 MP
Megapixel (approx.)	5 MP
Camera type	Quad camera
Zoom capability	Yes
Display
Built-in display	Yes
Display diagonal	20.3 cm (8")
Display resolution	1280 x 800 pixels
Touchscreen	Yes
Microphone
Microphone sensitivity	38 dB
Microphone frequency	100 - 8000 Hz
Microphone mute	Yes
Number of microphones	4
Microphone colour	Black
Sound pressure level (max)	75 dB
Security
Security algorithms	256-bit AES
Features
Cable lock slot	Yes
Cable lock slot type	Kensington
Computer system
Computer system type	Mini PC
Processor family	Qualcomm Snapdragon
Operating system installed	Android
Processor model	QCS8250
Computer case
Computer system type	Mini PC
Processor family	Qualcomm Snapdragon
Operating system installed	Android
Operational conditions
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	20 - 90%
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 80%
Power
DC input voltage	12 V
Current	3 A
Power source type	DC
Weight & dimensions
Camera dimensions (WxDxH)	84.5 x 84.5 x 274.9 mm
Interface module dimensions (W x D x H)	170 x 170 x 41.3 mm
Interface module weight	750 g
Camera weight	800 g
Packaging content
Packaging content	✓ RXV200 ✓ RXVCam360 ✓ RX-PAD ✓ 12V 3A Power Adapter (100-240V) ✓ USB Type C cable ✓ Ethernet cable
Cables included	LAN (RJ-45), USB Type-C
AC adapter included	Yes

Manufacturer

AudioCodes

PDF Url

https://objects.icecat.biz/objec
