Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km
Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km

Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km

Avaibility -

In stock

SKU - DN-81002
  £34.41
1.
Free Next Day Delivery over
Price Match Guarantee.
Talk to a Expert on Live Chat.
The plug and play fiber connection

- The Plug & Play fiber optic link enables quick installation
- Sends data in high quality and additionally provides excellent reliability
- Distance up to 80km at a maximum data rate of 1.25Gbps
- Operating temperature: 0 °C ~ 70 °C

The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.
SKU DN-81002
EAN 4016032305675
Specification
Performance
SFP transceiver typeFiber optic
Digital Diagnostics Monitoring (DDM)No
Fiber optic connectorLC
Networking standardsIEEE 802.3z
Maximum transfer distance80000 m
Wavelength1550 nm
Fiber ports quantity1
Fiber cable diameters supported (core/cladding)9/125 µm
Tx power (min)0 dBmW
Tx power (max)5 dBmW
Rx power (min)-32 dBmW
Cabling technology1000Base-LX
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Single-mode fiber (SMF) supportedYes
Ethernet interface typeGigabit Ethernet
SFP transceiver standardLX
Country of originChina
Plug and PlayYes
Hot-Plug supportYes
Brand compatibilityMSA Compliant
Harmonized System (HS) code85369010
Features
Plug and PlayYes
Hot-Plug supportYes
Brand compatibilityMSA Compliant
Country of originChina
Power
Input voltage3.3 V
Network
SFP transceiver typeFiber optic
Fiber optic connectorLC
Networking standardsIEEE 802.3z
Fiber ports quantity1
Cabling technology1000Base-LX
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Ethernet interface typeGigabit Ethernet
Technical details
Package width115 mm
Plug and PlayYes
Hot-Plug supportYes
Maximum transfer distance80000 m
Wavelength1550 nm
Fiber cable diameters supported (core/cladding)9/125 µm
Tx power (min)0 dBmW
Tx power (max)5 dBmW
Rx power (min)-32 dBmW
Cabling technology1000Base-LX
Ports & interfaces
Fiber ports quantity1
Packaging data
Package volume310.5 cm³
Package depth90 mm
Package width115 mm
Package weight35.417 g
Weight & dimensions
Package volume310.5 cm³
Package depth90 mm
Package width115 mm
Package weight35.417 g
Logistics data
Country of originChina
Harmonized System (HS) code85369010
UK Trade Tariff code85176200
Manufacturer Digitus
